| MODEL | C600-05 | C600-12 | C600-15 | C600-24 | C600-36 | C600-48 |
|
| INPUT | VOLTAGE | AC 90 ~ 130 180~260V |
| FREQUENCY | 47 ~ 440 |
| INRUSH CURRENT | 25A(115V AC INPUT), 50A(230V AC INPUT) |
| OUTPUT | VOLTAGE (V) | 5 | 12 | 15 | 24 | 36 | 48 |
| CURRENT (A) | 120 | 50 | 40 | 25 | 16.6 | 12.5 |
| LINE REGULATION (%) | 0.5 MAX |
| LOAD REGULATION (%) | 0.9 MAX |
| VOUT ADSUSTABLE RANGE (%) | VOUT x 10 (Typ) |
| TEMP. COEFFICIENT (%) 1 | 0.05 (0 ~ +50) |
| HOLD-UP TIME | 20 (MIN) |
| RIPPLE / NOISE (mV P-P) | VOUT x 1% (MAX) |
OUTPUT
PROTECTIONS | OVER CURRENT PROTECTION | 130~180% OF RATED IOUT(AUTOMATIC RECOVERY) |
| OVER VOLTAGE PROTECTION | 120~140% OF RATED VOUT(SHUT DOWN LATCH) |
| EFFICIENCY | 75% (TYP) |
| OPERATING TEMPERATURE () | -10 ~ +50 (AT FULL RATED LOAD) |
| STORAGE TEMPERATURE () | -20 ~ +75 (MIN) |
| OPERATING HUMIDITY (%) | 10 ~ 90RH (NON CONDENSING) |
| TURN ON RESPONS (mS) | 300 (MAX) |
WITHSTAND VOLTAGE (INPUT  CHASSIS, INPUT OUTPUT) : 1.5KVAC 1MINUTE |
| ISOLATION RESISTANCE (OUTPUT CHASSIS) : 100M BY 500V DC MEGGER |
DH-C600-05
CHASSIS, INPUT
